VFD, Power, C&I (Factory Automation)
From power and VFD cables to control and communication cables, we provide a variety of cables to fill your factory automation needs. Click on the catalogue and links below to obtain more information.
Southwire Factory Automation – Variable Frequency Drive VFD Cables
Flexible Cable Type TC-ER, Tinned Copper Conductors, Cross Linked Insulation Type RHH/RHW-2, Thermoplastic Elastomer Jacket, 90°C Dry or Wet -40°C
Flexible Cable Type TC-ER, Tinned Copper Conductors, Cross Linked Insulation Type RHH/RHW-2, Shielded Pair Thermoplastic Elastomer Jacket, 90°C Dry or Wet -40°C
Flexible Cable Type TC-ER, Tinned Copper Conductors, Crosslinked Insulation Type XHHW-2. Thermoplastic Elastomer Jacket. Rated 90C Dry or Wet, -40C
PVC Power Cable Type TC-ER VFD, 2000V, Three Conductor Copper, Cross Linked Polyethylene (XLPE) insulation RHH/RHW-2, 3 Symmetrical Bare CU Ground
PVC Jacket, RHH/RHW-2 Flexible, Type TC-ER VFD Power Cable 2000V Three Conductor Copper, XLPE insulation, RHH/ RHW-2, PVC Jacket, 3 Symmetrical Bare CU Ground
Type MC-HL, 600V Copper Conductors, XLPE Insulation XHHW-2 Continuous Corrugated Welded Armor (Armor-X), PVC Jacket with 1 Insulated Green CU Ground
Type MC-HL Control Cable 600V CU Conductors, XLPE Insulation, XHHW-2 Continuous Corrugated Welded Armor (Armor-X), PVC Jacket, 3 Bare CU Ground
MV-105 VFD, Type MV-105, 3 Conductor CU, 115 Mils No Lead Rubber NL-EPR, 133% Insulation, Continuous Corrugated Welded Aluminum Armor (Armor-X), PVC
PVC, Type MV-105, 3 Conductor Cu, 140 Mils No Lead Ethylene Propylene Rubber (NL-EPR) 133% Insulation Level, Continuous Corrugated Welded Armor (Armor-X)
PVC, Type MV-105, 3Conductor Copper, 220 Mils No Lead Ethylene Propylene Rubber (NL-EPR), Continuous Corrugated Welded Aluminum Armor (Armor-X)
Cu Tape Shield, PVC Jacket, RHH/RHW-2, Type TC-ER VFD Power Cable 2000V, 3 Conductor Cu, Cross Linked Polyethylene (XLPE) insulation RHH/RHW-2
Tape: Conducting copper foil tape conforming to UL 510
Braid: Flexible tinned copper braid bonding strap with attached lug. Individual wires conform to ASTM B33 3
Cap: Nickel plated brass gland cap sized for body .
Seal: Chloroprene rubber (CR) fitting providing an ingress protection rating of IP 68 (5 bar, 30 seconds)
Southwire Factory Automation – Single Core Cables
90°C Wet or Dry. 600V, Flexible Stranded CU Conductor. PVC Insulation and Nylon Jacket (THHN/THWN-2). Oil & Gasoline Resistant. Sunlight Resistant, Flame Resistant
LSZH-TS 90°C Wet or Dry. 600V or 1000V. Flexible Stranded Cu Conductor. Thermoset Low Smoke Zero Halogen. Oil, Gasoline & Sun resistant
Type XHHW-2 1000V, Type RW90 600V. Flexible Tinned Cu. Cross-Linked Polyethylene (XLPE) Insulation. Heat, Flame, Moisture, Gasoline, Oil, Sunlight Resistant
105°C Dry. 60/75°C Moisture Resistant. 600/1000 Volts. Flexible Stranded Tinned Copper Conductor. With PVC outer insulation
Southwire Factory Automation – Power and Control Cables
PVC, Type TC-ER Shielded, CU Conductors, Polyvinyl PVC with nylon layer Insulation, Thermoplastic Elastomer Jacket, 90°C Dry 75°C Wet -40°C. Cold Impact Method 4
PVC TPE Jacket, 300V Type PLTC-ER ITC-ER Bare Copper Conductors PVC/Nylon Insulation with TPE Jacket Oil Res I/II 90C -40C. Cold Impact Method 4
THHN TPE Jacket, Type TC-ER Machine Tray Power Cable 600/1000V Cu Conductors, PVC with nylon layer Insulation Thermoplastic Elastomer Jacket
PVC THHN TPE Jacket, Type TC-ER Machine Tray Control Cable 600/1000V Cur Conductors, PVC with nylon layer Insulation Thermoplastic Elastomer Jacket
