Three Core MV Cable (MV-105)
Southwire is North America’s largest wire and cable manufacturer, manufacturing over 200,000 wire and cable products https://thompsongws.com/ul-csa-products/
One of those product families is medium voltage cables, where they offer a range of products from 2.4kV up to 35kV in either copper or aluminium, with either EPR or XLPE insulation and PVC, CPE or LSZH jackets.
Southwire’s 3-core Medium Voltage cables are suited for use in wet and dry areas, conduits, ducts, troughs, trays, direct burial, aerial supported by a messenger, and where superior electrical properties are desired. For uses in Class I, II, and III, Division 2 hazardous locations per NEC Article 501 and 502. Type (TC-ER) per NEC 336.10.
From a shielding perspective they will all come with copper tape shields and if an armour is required, they can be manufactured with an Aluminium Interlocked Armour (AIA) or Southwire’s famous ARMOR-X brand, which is a continuous corrugated welded armour (abbreviated to CCW or MC-HL) – check our FAQs page for more information on the ARMOR-X product here: https://thompsongws.com/faqs-armor-x/
Southwire 2kV 3c MV Power Cable 2 awg – 750kcmil
2kV Three-Core Cable
Three Grounds Cu Tape Shield PVC Jacket. RHH/RHW-2 Variable Frequency Drive (VFD) Type TC-ER VFD Power Cable
100% IL ARMOR-X® PVC Jacket.
MV 105 Tray Rated, Sunlight Resistant, Direct Burial, Three Conductor Copper
Southwire 5kV 3c MV Power Cable 2 awg – 750kcmil MV-105
5kV Three-Core Cable
133/100% IL PVC Jacket. MV
105 Tray Rated, Sunlight Resistant, For Direct Burial
100% TS AIA PVC MV-105, Three Conductor Aluminum, 90 Mils No Lead 100% Insulation
133/100% IL AIA PVC Jacket.
MV 105 Tray Rated, Sunlight Resistant, For Direct Burial
133/100% IL ARMOR-X® PVC
Jacket. MV 105 Tray Rated, Sunlight Resistant For Direct Burial
133/100% IL CPE-TP Jacket.
MV 105 Tray Rated, Sunlight Resistant, For Direct Burial
Southwire 15kV 3c MV Power Cable 1 awg – 750kcmil MV-105
15kV Three-Core Cable
133% IL Black PVC Jacket. MV
105 Tray Rated, Sunlight Resistant. For Direct Burial
133% IL AIA Red PVC Jacket.
MV 105 Tray Rated, Sunlight Resistant, For Direct Burial
133% IL ARMOR-X® Red PVC Jacket. MV 105 Tray Rated, Sunlight Resistant, For Direct Burial
133% IL Black CPE-TP Jacket.
MV 105 Tray Rated, Sunlight Resistant, For Direct Burial
133% IL Black PVC Jacket. MV 105
Tray Rated, 3-Core, Sunlight Resistant, For Direct Burial
133% IL Black PVC Jacket.
MV 105 Tray Rated, Sunlight Resistant, For Direct Burial
Southwire 25kV 3c MV Power Cable 2 awg – 750kcmil MV-105
25kV Three-Core Cable
133% IL Black PVC Jacket. MV
105 Tray Rated, 3 Core Cable, Sunlight Resistant, For Direct Burial
Southwire 35kV 3c MV Power Cable 1 awg – 350kcmil MV-105
35kV Three-Core Cable
133% IL Black PVC Jacket. MV
105 Tray Rated, Sunlight Resistant, For Direct Burial
133% AIA Insulation Level. PVC MV-105, No Lead Ethylene Propylene Aluminum Interlocked Armor
133% IL ARMOR-X® Orange.
PVC Jacket. MV 105 Tray Rated, Sunlight Resist, Burial
133% IL Black PVC Jacket. MV 105
Tray Rated, Sunlight Resistant, For Direct Burial
